Associated Spring Raymond - 31.12mm OD, 5.26mm Wire, 3-1/2" Free Length, Compression Spring - 259.4 Lb Spring Rating, 742.5 N Max Work Load, Music Wire
Item #: 69074326
Brand: Associated Spring Raymond
Model #: C12252073500M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 31.12 |
| Outside Diameter (Decimal Inch) | 1.2250 |
| Free Length (mm) | 88.90 |
| Free Length (Decimal Inch) | 3-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 259.4000 |
| Maximum Work Load (N) | 742-1/2 |
| Solid Height (mm) | 63.86 |
| Solid Height (Decimal Inch) | 2.5140 |
| Material | Music Wire |
| Wire Size (mm) | 5.26 |
| Wire Size (Decimal Inch) | 0.2070 |
