Associated Spring Raymond - 37.08mm OD, 3.18mm Wire, 3-1/2" Free Length, Compression Spring - 23.3 Lb Spring Rating, 158.39 N Max Work Load, Music Wire
Item #: 69073872
Brand: Associated Spring Raymond
Model #: C14601253500M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 37.08 |
| Outside Diameter (Decimal Inch) | 1.4600 |
| Free Length (mm) | 88.90 |
| Free Length (Decimal Inch) | 3-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 23.3000 |
| Maximum Work Load (N) | 158.38999939 |
| Solid Height (mm) | 27.99 |
| Solid Height (Decimal Inch) | 1.1020 |
| Material | Music Wire |
| Wire Size (mm) | 3.18 |
| Wire Size (Decimal Inch) | 1/8 |
