Associated Spring Raymond - 37.08mm OD, 3.18mm Wire, 3-1/2" Free Length, Compression Spring - 19.41 Lb Spring Rating, 131.93 N Max Work Load, Stainless Steel
Item #: 69073856
Brand: Associated Spring Raymond
Model #: C14601253500S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 37.08 |
| Outside Diameter (Decimal Inch) | 1.4600 |
| Free Length (mm) | 88.90 |
| Free Length (Decimal Inch) | 3-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 19.4100 |
| Maximum Work Load (N) | 131.92999268 |
| Solid Height (mm) | 27.99 |
| Solid Height (Decimal Inch) | 1.1020 |
| Material | Stainless Steel |
| Wire Size (mm) | 3.18 |
| Wire Size (Decimal Inch) | 1/8 |
