Associated Spring Raymond - 27.94mm OD, 2.16mm Wire, 3-1/2" Free Length, Compression Spring - 9.6 Lb Spring Rating, 70.9 N Max Work Load, Music Wire
Item #: 69073120
Brand: Associated Spring Raymond
Model #: C11000853500M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 27.94 |
| Outside Diameter (Decimal Inch) | 1.1000 |
| Free Length (mm) | 88.90 |
| Free Length (Decimal Inch) | 3-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 9.6000 |
| Maximum Work Load (N) | 70.90000153 |
| Solid Height (mm) | 21.62 |
| Solid Height (Decimal Inch) | 0.8510 |
| Material | Music Wire |
| Wire Size (mm) | 2.16 |
| Wire Size (Decimal Inch) | 0.0850 |
