Associated Spring Raymond - 24.77mm OD, 3.18mm Wire, 1-1/2" Free Length, Compression Spring - 124.3 Lb Spring Rating, 231.47 N Max Work Load, Music Wire
Item #: 69072361
Brand: Associated Spring Raymond
Model #: C09751251500M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 24.77 |
| Outside Diameter (Decimal Inch) | 0.9750 |
| Free Length (mm) | 38.10 |
| Free Length (Decimal Inch) | 1-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 124.3000 |
| Maximum Work Load (N) | 231.47000122 |
| Solid Height (mm) | 22.53 |
| Solid Height (Decimal Inch) | 0.8870 |
| Material | Music Wire |
| Wire Size (mm) | 3.18 |
| Wire Size (Decimal Inch) | 1/8 |
