Associated Spring Raymond - 24.77mm OD, 2.67mm Wire, 2-3/4" Free Length, Compression Spring - 31.4 Lb Spring Rating, 143.18 N Max Work Load, Music Wire
Item #: 69072098
Brand: Associated Spring Raymond
Model #: C09751052750M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 24.77 |
| Outside Diameter (Decimal Inch) | 0.9750 |
| Free Length (mm) | 69.85 |
| Free Length (Decimal Inch) | 2-3/4 |
| Spring Rate Pounds per Inch (Pounds) | 31.4000 |
| Maximum Work Load (N) | 143.17999268 |
| Solid Height (mm) | 29.18 |
| Solid Height (Decimal Inch) | 1.1490 |
| Material | Music Wire |
| Wire Size (mm) | 2.67 |
| Wire Size (Decimal Inch) | 0.1050 |
