Associated Spring Raymond - 21.6mm OD, 2.5mm Wire, 2-3/4" Free Length, Compression Spring - 25.91 Lb Spring Rating, 112.05 N Max Work Load, Stainless Steel
Item #: 69071298
Brand: Associated Spring Raymond
Model #: C08500982750S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 21.59 |
| Outside Diameter (Decimal Inch) | 0.8500 |
| Free Length (mm) | 69.85 |
| Free Length (Decimal Inch) | 2-3/4 |
| Spring Rate Pounds per Inch (Pounds) | 25.9100 |
| Maximum Work Load (N) | 112.05000305 |
| Solid Height (mm) | 31.22 |
| Solid Height (Decimal Inch) | 1.2290 |
| Material | Stainless Steel |
| Wire Size (mm) | 2.49 |
| Wire Size (Decimal Inch) | 0.0980 |
