Associated Spring Raymond - 21.6mm OD, 2.5mm Wire, 25.4mm Free Length, Compression Spring - 82.22 Lb Spring Rating, 112.05 N Max Work Load, Stainless Steel
Item #: 69071165
Brand: Associated Spring Raymond
Model #: C08500981000S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 21.59 |
| Outside Diameter (Decimal Inch) | 0.8500 |
| Free Length (mm) | 25.40 |
| Free Length (Decimal Inch) | 1 |
| Spring Rate Pounds per Inch (Pounds) | 82.2200 |
| Maximum Work Load (N) | 112.05000305 |
| Solid Height (mm) | 14.10 |
| Solid Height (Decimal Inch) | 0.5550 |
| Material | Stainless Steel |
| Wire Size (mm) | 2.49 |
| Wire Size (Decimal Inch) | 0.0980 |
