Associated Spring Raymond - 21.6mm OD, 2.34mm Wire, 1-1/4" Free Length, Compression Spring - 49 Lb Spring Rating, 109.44 N Max Work Load, Stainless Steel
Item #: 69071017
Brand: Associated Spring Raymond
Model #: C08500921250X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 21.59 |
| Outside Diameter (Decimal Inch) | 0.8500 |
| Free Length (mm) | 31-3/4 |
| Free Length (Decimal Inch) | 1-1/4 |
| Spring Rate Pounds per Inch (Pounds) | 49.0000 |
| Maximum Work Load (N) | 109.44000244 |
| Solid Height (mm) | 15.24 |
| Solid Height (Decimal Inch) | 0.6000 |
| Material | Stainless Steel |
| Wire Size (mm) | 2.34 |
| Wire Size (Decimal Inch) | 0.0920 |
