Associated Spring Raymond - 21.6mm OD, 1.88mm Wire, 2-1/2" Free Length, Compression Spring - 10.33 Lb Spring Rating, 51.37 N Max Work Load, Stainless Steel
Item #: 69070381
Brand: Associated Spring Raymond
Model #: C08500742500S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 21.59 |
| Outside Diameter (Decimal Inch) | 0.8500 |
| Free Length (mm) | 63-1/2 |
| Free Length (Decimal Inch) | 2-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 10.3300 |
| Maximum Work Load (N) | 51.36999893 |
| Solid Height (mm) | 18.67 |
| Solid Height (Decimal Inch) | 0.7350 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.88 |
| Wire Size (Decimal Inch) | 0.0740 |
