Associated Spring Raymond - 21.6mm OD, 1.88mm Wire, 50.8mm Free Length, Compression Spring - 13.2 Lb Spring Rating, 59.02 N Max Work Load, Stainless Steel
Item #: 69070373
Brand: Associated Spring Raymond
Model #: C08500742000X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 21.59 |
| Outside Diameter (Decimal Inch) | 0.8500 |
| Free Length (mm) | 50.80 |
| Free Length (Decimal Inch) | 2 |
| Spring Rate Pounds per Inch (Pounds) | 13.2000 |
| Maximum Work Load (N) | 59.02000046 |
| Solid Height (mm) | 15.70 |
| Solid Height (Decimal Inch) | 0.6180 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.88 |
| Wire Size (Decimal Inch) | 0.0740 |
