Associated Spring Raymond - 18.3mm OD, 2.44mm Wire, 2-1/4" Free Length, Compression Spring - 64.7 Lb Spring Rating, 201.63 N Max Work Load, Music Wire
Item #: 69069557
Brand: Associated Spring Raymond
Model #: C07200962250M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 18.29 |
| Outside Diameter (Decimal Inch) | 0.7200 |
| Free Length (mm) | 57.15 |
| Free Length (Decimal Inch) | 2-1/4 |
| Spring Rate Pounds per Inch (Pounds) | 64.7000 |
| Maximum Work Load (N) | 201.63000488 |
| Solid Height (mm) | 26.26 |
| Solid Height (Decimal Inch) | 1.0340 |
| Material | Music Wire |
| Wire Size (mm) | 2.44 |
| Wire Size (Decimal Inch) | 0.0960 |
