Associated Spring Raymond - 18.3mm OD, 2.06mm Wire, 1-1/2" Free Length, Compression Spring - 45.5 Lb Spring Rating, 127.75 N Max Work Load, Music Wire
Item #: 69068765
Brand: Associated Spring Raymond
Model #: C07200811500M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 18.29 |
| Outside Diameter (Decimal Inch) | 0.7200 |
| Free Length (mm) | 38.10 |
| Free Length (Decimal Inch) | 1-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 45.5000 |
| Maximum Work Load (N) | 127-3/4 |
| Solid Height (mm) | 16.89 |
| Solid Height (Decimal Inch) | 0.6650 |
| Material | Music Wire |
| Wire Size (mm) | 2.06 |
| Wire Size (Decimal Inch) | 0.0810 |
