Associated Spring Raymond - 18.3mm OD, 1.65mm Wire, 2-3/4" Free Length, Compression Spring - 9.08 Lb Spring Rating, 48.39 N Max Work Load, Stainless Steel
Item #: 69067940
Brand: Associated Spring Raymond
Model #: C07200652750S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 18.29 |
| Outside Diameter (Decimal Inch) | 0.7200 |
| Free Length (mm) | 69.85 |
| Free Length (Decimal Inch) | 2-3/4 |
| Spring Rate Pounds per Inch (Pounds) | 9.0800 |
| Maximum Work Load (N) | 48.38999939 |
| Solid Height (mm) | 18.14 |
| Solid Height (Decimal Inch) | 0.7140 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.65 |
| Wire Size (Decimal Inch) | 0.0650 |
