Associated Spring Raymond - 18.3mm OD, 1.4mm Wire, 76.2mm Free Length, Compression Spring - 4.8 Lb Spring Rating, 30.13 N Max Work Load, Stainless Steel
Item #: 69067080
Brand: Associated Spring Raymond
Model #: C07200553000X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 18.29 |
| Outside Diameter (Decimal Inch) | 0.7200 |
| Free Length (mm) | 76.20 |
| Free Length (Decimal Inch) | 3 |
| Spring Rate Pounds per Inch (Pounds) | 4.8000 |
| Maximum Work Load (N) | 30.12999916 |
| Solid Height (mm) | 15.06 |
| Solid Height (Decimal Inch) | 0.5930 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.40 |
| Wire Size (Decimal Inch) | 0.0550 |
