Associated Spring Raymond - 15.24mm OD, 2.5mm Wire, 3-1/4" Free Length, Compression Spring - 70.4 Lb Spring Rating, 245.26 N Max Work Load, Music Wire
Item #: 69066595
Brand: Associated Spring Raymond
Model #: C06000983250M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 15.24 |
| Outside Diameter (Decimal Inch) | 0.6000 |
| Free Length (mm) | 82.55 |
| Free Length (Decimal Inch) | 3-1/4 |
| Spring Rate Pounds per Inch (Pounds) | 70.4000 |
| Maximum Work Load (N) | 245.25999451 |
| Solid Height (mm) | 44.55 |
| Solid Height (Decimal Inch) | 1.7540 |
| Material | Music Wire |
| Wire Size (mm) | 2.49 |
| Wire Size (Decimal Inch) | 0.0980 |
