Associated Spring Raymond - 15.24mm OD, 2.5mm Wire, 2-1/2" Free Length, Compression Spring - 77.7 Lb Spring Rating, 176.35 N Max Work Load, Stainless Steel
Item #: 69066553
Brand: Associated Spring Raymond
Model #: C06000982500X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 15.24 |
| Outside Diameter (Decimal Inch) | 0.6000 |
| Free Length (mm) | 63-1/2 |
| Free Length (Decimal Inch) | 2-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 77.7000 |
| Maximum Work Load (N) | 176.35000610 |
| Solid Height (mm) | 35.43 |
| Solid Height (Decimal Inch) | 1.3950 |
| Material | Stainless Steel |
| Wire Size (mm) | 2.49 |
| Wire Size (Decimal Inch) | 0.0980 |
