Associated Spring Raymond - 15.24mm OD, 2.16mm Wire, 1-1/2" Free Length, Compression Spring - 74 Lb Spring Rating, 119.77 N Max Work Load, Stainless Steel
Item #: 69065597
Brand: Associated Spring Raymond
Model #: C06000851500X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 15.24 |
| Outside Diameter (Decimal Inch) | 0.6000 |
| Free Length (mm) | 38.10 |
| Free Length (Decimal Inch) | 1-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 74.0000 |
| Maximum Work Load (N) | 119.76999664 |
| Solid Height (mm) | 19.84 |
| Solid Height (Decimal Inch) | 0.7810 |
| Material | Stainless Steel |
| Wire Size (mm) | 2.16 |
| Wire Size (Decimal Inch) | 0.0850 |
