Associated Spring Raymond - 15.24mm OD, 1.7mm Wire, 22.35mm Free Length, Compression Spring - 41.65 Lb Spring Rating, 62.89 N Max Work Load, Stainless Steel
Item #: 69064582
Brand: Associated Spring Raymond
Model #: C06000670880S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 15.24 |
| Outside Diameter (Decimal Inch) | 0.6000 |
| Free Length (mm) | 22.35 |
| Free Length (Decimal Inch) | 0.8800 |
| Spring Rate Pounds per Inch (Pounds) | 41.6500 |
| Maximum Work Load (N) | 62.88999939 |
| Solid Height (mm) | 10.19 |
| Solid Height (Decimal Inch) | 0.4010 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.70 |
| Wire Size (Decimal Inch) | 0.0670 |
