Associated Spring Raymond - 15.24mm OD, 1.7mm Wire, 3/4" Free Length, Compression Spring - 66 Lb Spring Rating, 93.41 N Max Work Load, Music Wire
Item #: 69064541
Brand: Associated Spring Raymond
Model #: C06000670750M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 15.24 |
| Outside Diameter (Decimal Inch) | 0.6000 |
| Free Length (mm) | 19.05 |
| Free Length (Decimal Inch) | 3/4 |
| Spring Rate Pounds per Inch (Pounds) | 66.0000 |
| Maximum Work Load (N) | 93.41000366 |
| Solid Height (mm) | 8.53 |
| Solid Height (Decimal Inch) | 0.3360 |
| Material | Music Wire |
| Wire Size (mm) | 1.70 |
| Wire Size (Decimal Inch) | 0.0670 |
