Associated Spring Raymond - 15.24mm OD, 1.6mm Wire, 2-1/4" Free Length, Compression Spring - 13.2 Lb Spring Rating, 52.31 N Max Work Load, Stainless Steel
Item #: 69064459
Brand: Associated Spring Raymond
Model #: C06000632250X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 15.24 |
| Outside Diameter (Decimal Inch) | 0.6000 |
| Free Length (mm) | 57.15 |
| Free Length (Decimal Inch) | 2-1/4 |
| Spring Rate Pounds per Inch (Pounds) | 13.2000 |
| Maximum Work Load (N) | 52.31000137 |
| Solid Height (mm) | 19.51 |
| Solid Height (Decimal Inch) | 0.7680 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.60 |
| Wire Size (Decimal Inch) | 0.0630 |
