Associated Spring Raymond - 15.24mm OD, 1.6mm Wire, 1-1/2" Free Length, Compression Spring - 24 Lb Spring Rating, 80.07 N Max Work Load, Music Wire
Item #: 69064384
Brand: Associated Spring Raymond
Model #: C06000631500M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 15.24 |
| Outside Diameter (Decimal Inch) | 0.6000 |
| Free Length (mm) | 38.10 |
| Free Length (Decimal Inch) | 1-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 24.0000 |
| Maximum Work Load (N) | 80.06999969 |
| Solid Height (mm) | 13.36 |
| Solid Height (Decimal Inch) | 0.5260 |
| Material | Music Wire |
| Wire Size (mm) | 1.60 |
| Wire Size (Decimal Inch) | 0.0630 |
