Associated Spring Raymond - 15.24mm OD, 1.5mm Wire, 1-3/4" Free Length, Compression Spring - 13.74 Lb Spring Rating, 44.3 N Max Work Load, Stainless Steel
Item #: 69064145
Brand: Associated Spring Raymond
Model #: C06000591750S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 15.24 |
| Outside Diameter (Decimal Inch) | 0.6000 |
| Free Length (mm) | 44.45 |
| Free Length (Decimal Inch) | 1-3/4 |
| Spring Rate Pounds per Inch (Pounds) | 13.7400 |
| Maximum Work Load (N) | 44.29999924 |
| Solid Height (mm) | 14.48 |
| Solid Height (Decimal Inch) | 0.5700 |
| Material | Stainless Steel |
| Wire Size (mm) | 1-1/2 |
| Wire Size (Decimal Inch) | 0.0590 |
