Associated Spring Raymond - 15.24mm OD, 1.4mm Wire, 25.4mm Free Length, Compression Spring - 24 Lb Spring Rating, 53.38 N Max Work Load, Music Wire
Item #: 69063733
Brand: Associated Spring Raymond
Model #: C06000551000M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 15.24 |
| Outside Diameter (Decimal Inch) | 0.6000 |
| Free Length (mm) | 25.40 |
| Free Length (Decimal Inch) | 1 |
| Spring Rate Pounds per Inch (Pounds) | 24.0000 |
| Maximum Work Load (N) | 53.38000107 |
| Solid Height (mm) | 7.72 |
| Solid Height (Decimal Inch) | 0.3040 |
| Material | Music Wire |
| Wire Size (mm) | 1.40 |
| Wire Size (Decimal Inch) | 0.0550 |
