Associated Spring Raymond - 15.24mm OD, 1.4mm Wire, 3/4" Free Length, Compression Spring - 33 Lb Spring Rating, 53.38 N Max Work Load, Music Wire
Item #: 69063683
Brand: Associated Spring Raymond
Model #: C06000550750M
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Compression |
Outside Diameter (mm) | 15.24 |
Outside Diameter (Decimal Inch) | 0.6000 |
Free Length (mm) | 19.05 |
Free Length (Decimal Inch) | 3/4 |
Spring Rate Pounds per Inch (Pounds) | 33.0000 |
Maximum Work Load (N) | 53.38000107 |
Solid Height (mm) | 6.38 |
Solid Height (Decimal Inch) | 0.2510 |
Material | Music Wire |
Wire Size (mm) | 1.40 |
Wire Size (Decimal Inch) | 0.0550 |
