Associated Spring Raymond - 15.24mm OD, 1.14mm Wire, 50.8mm Free Length, Compression Spring - 4.8 Lb Spring Rating, 20.72 N Max Work Load, Stainless Steel
Item #: 69063295
Brand: Associated Spring Raymond
Model #: C06000452000X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 15.24 |
| Outside Diameter (Decimal Inch) | 0.6000 |
| Free Length (mm) | 50.80 |
| Free Length (Decimal Inch) | 2 |
| Spring Rate Pounds per Inch (Pounds) | 4.8000 |
| Maximum Work Load (N) | 20.71999931 |
| Solid Height (mm) | 10.19 |
| Solid Height (Decimal Inch) | 0.4010 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.14 |
| Wire Size (Decimal Inch) | 0.0450 |
