Associated Spring Raymond - 12.2mm OD, 1.88mm Wire, 3-1/2" Free Length, Compression Spring - 30.4 Lb Spring Rating, 154.75 N Max Work Load, Music Wire
Item #: 69062743
Brand: Associated Spring Raymond
Model #: C04800743500M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 12.19 |
| Outside Diameter (Decimal Inch) | 0.4800 |
| Free Length (mm) | 88.90 |
| Free Length (Decimal Inch) | 3-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 30.4000 |
| Maximum Work Load (N) | 154-3/4 |
| Solid Height (mm) | 45.52 |
| Solid Height (Decimal Inch) | 1.7920 |
| Material | Music Wire |
| Wire Size (mm) | 1.88 |
| Wire Size (Decimal Inch) | 0.0740 |
