Associated Spring Raymond - 15.24mm OD, 1.24mm Wire, 2-1/4" Free Length, Compression Spring - 6.8 Lb Spring Rating, 37.37 N Max Work Load, Music Wire
Item #: 69062073
Brand: Associated Spring Raymond
Model #: C06000492250M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 15.24 |
| Outside Diameter (Decimal Inch) | 0.6000 |
| Free Length (mm) | 57.15 |
| Free Length (Decimal Inch) | 2-1/4 |
| Spring Rate Pounds per Inch (Pounds) | 6.8000 |
| Maximum Work Load (N) | 37.36999893 |
| Solid Height (mm) | 12.83 |
| Solid Height (Decimal Inch) | 0.5050 |
| Material | Music Wire |
| Wire Size (mm) | 1.24 |
| Wire Size (Decimal Inch) | 0.0490 |
