Associated Spring Raymond - 15.24mm OD, 1.6mm Wire, 22.35mm Free Length, Compression Spring - 36.65 Lb Spring Rating, 52.49 N Max Work Load, Stainless Steel
Item #: 69061927
Brand: Associated Spring Raymond
Model #: C06000630880S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 15.24 |
| Outside Diameter (Decimal Inch) | 0.6000 |
| Free Length (mm) | 22.35 |
| Free Length (Decimal Inch) | 0.8800 |
| Spring Rate Pounds per Inch (Pounds) | 36.6500 |
| Maximum Work Load (N) | 52.49000168 |
| Solid Height (mm) | 8.71 |
| Solid Height (Decimal Inch) | 0.3430 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.60 |
| Wire Size (Decimal Inch) | 0.0630 |
