Associated Spring Raymond - 18.3mm OD, 2.06mm Wire, 50.8mm Free Length, Compression Spring - 27.6 Lb Spring Rating, 87.96 N Max Work Load, Stainless Steel
Item #: 69061323
Brand: Associated Spring Raymond
Model #: C07200812000X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 18.29 |
| Outside Diameter (Decimal Inch) | 0.7200 |
| Free Length (mm) | 50.80 |
| Free Length (Decimal Inch) | 2 |
| Spring Rate Pounds per Inch (Pounds) | 27.6000 |
| Maximum Work Load (N) | 87.95999908 |
| Solid Height (mm) | 20.90 |
| Solid Height (Decimal Inch) | 0.8230 |
| Material | Stainless Steel |
| Wire Size (mm) | 2.06 |
| Wire Size (Decimal Inch) | 0.0810 |
