Associated Spring Raymond - 21.6mm OD, 1.73mm Wire, 1-1/4" Free Length, Compression Spring - 16.5 Lb Spring Rating, 47.06 N Max Work Load, Stainless Steel
Item #: 69060960
Brand: Associated Spring Raymond
Model #: C08500681250X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 21.59 |
| Outside Diameter (Decimal Inch) | 0.8500 |
| Free Length (mm) | 31-3/4 |
| Free Length (Decimal Inch) | 1-1/4 |
| Spring Rate Pounds per Inch (Pounds) | 16.5000 |
| Maximum Work Load (N) | 47.06000137 |
| Solid Height (mm) | 9.93 |
| Solid Height (Decimal Inch) | 0.3910 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.73 |
| Wire Size (Decimal Inch) | 0.0680 |
