Associated Spring Raymond - 21.6mm OD, 1.73mm Wire, 101.6mm Free Length, Compression Spring - 5.7 Lb Spring Rating, 48.66 N Max Work Load, Music Wire
Item #: 69060796
Brand: Associated Spring Raymond
Model #: C08500684000M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 21.59 |
| Outside Diameter (Decimal Inch) | 0.8500 |
| Free Length (mm) | 101.60 |
| Free Length (Decimal Inch) | 4 |
| Spring Rate Pounds per Inch (Pounds) | 5.7000 |
| Maximum Work Load (N) | 48.65999985 |
| Solid Height (mm) | 23.80 |
| Solid Height (Decimal Inch) | 0.9370 |
| Material | Music Wire |
| Wire Size (mm) | 1.73 |
| Wire Size (Decimal Inch) | 0.0680 |
