Associated Spring Raymond - 21.6mm OD, 2.06mm Wire, 25.4mm Free Length, Compression Spring - 39.6 Lb Spring Rating, 75.23 N Max Work Load, Stainless Steel
Item #: 69060606
Brand: Associated Spring Raymond
Model #: C08500811000X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 21.59 |
| Outside Diameter (Decimal Inch) | 0.8500 |
| Free Length (mm) | 25.40 |
| Free Length (Decimal Inch) | 1 |
| Spring Rate Pounds per Inch (Pounds) | 39.6000 |
| Maximum Work Load (N) | 75.23000336 |
| Solid Height (mm) | 11.05 |
| Solid Height (Decimal Inch) | 0.4350 |
| Material | Stainless Steel |
| Wire Size (mm) | 2.06 |
| Wire Size (Decimal Inch) | 0.0810 |
