Associated Spring Raymond - 21.6mm OD, 2.34mm Wire, 2-1/4" Free Length, Compression Spring - 30.4 Lb Spring Rating, 112.93 N Max Work Load, Music Wire
Item #: 69060325
Brand: Associated Spring Raymond
Model #: C08500922250M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 21.59 |
| Outside Diameter (Decimal Inch) | 0.8500 |
| Free Length (mm) | 57.15 |
| Free Length (Decimal Inch) | 2-1/4 |
| Spring Rate Pounds per Inch (Pounds) | 30.4000 |
| Maximum Work Load (N) | 112.93000031 |
| Solid Height (mm) | 24.05 |
| Solid Height (Decimal Inch) | 0.9470 |
| Material | Music Wire |
| Wire Size (mm) | 2.34 |
| Wire Size (Decimal Inch) | 0.0920 |
