Associated Spring Raymond - 24.77mm OD, 2.84mm Wire, 50.8mm Free Length, Compression Spring - 47.6 Lb Spring Rating, 163.12 N Max Work Load, Stainless Steel
Item #: 69059574
Brand: Associated Spring Raymond
Model #: C09751122000X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 24.77 |
| Outside Diameter (Decimal Inch) | 0.9750 |
| Free Length (mm) | 50.80 |
| Free Length (Decimal Inch) | 2 |
| Spring Rate Pounds per Inch (Pounds) | 47.6000 |
| Maximum Work Load (N) | 163.11999512 |
| Solid Height (mm) | 24.64 |
| Solid Height (Decimal Inch) | 0.9700 |
| Material | Stainless Steel |
| Wire Size (mm) | 2.84 |
| Wire Size (Decimal Inch) | 0.1120 |
