Associated Spring Raymond - 24.77mm OD, 3.18mm Wire, 22.35mm Free Length, Compression Spring - 205.42 Lb Spring Rating, 192.82 N Max Work Load, Stainless Steel
Item #: 69059558
Brand: Associated Spring Raymond
Model #: C09751250880S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 24.77 |
| Outside Diameter (Decimal Inch) | 0.9750 |
| Free Length (mm) | 22.35 |
| Free Length (Decimal Inch) | 0.8800 |
| Spring Rate Pounds per Inch (Pounds) | 205.4200 |
| Maximum Work Load (N) | 192.82000732 |
| Solid Height (mm) | 15.29 |
| Solid Height (Decimal Inch) | 0.6020 |
| Material | Stainless Steel |
| Wire Size (mm) | 3.18 |
| Wire Size (Decimal Inch) | 1/8 |
