Associated Spring Raymond - 24.77mm OD, 3.43mm Wire, 22.35mm Free Length, Compression Spring - 297.1 Lb Spring Rating, 267.04 N Max Work Load, Stainless Steel
Item #: 69059384
Brand: Associated Spring Raymond
Model #: C09751350880X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 24.77 |
| Outside Diameter (Decimal Inch) | 0.9750 |
| Free Length (mm) | 22.35 |
| Free Length (Decimal Inch) | 0.8800 |
| Spring Rate Pounds per Inch (Pounds) | 297.1000 |
| Maximum Work Load (N) | 267.04000854 |
| Solid Height (mm) | 16.33 |
| Solid Height (Decimal Inch) | 0.6430 |
| Material | Stainless Steel |
| Wire Size (mm) | 3.43 |
| Wire Size (Decimal Inch) | 0.1350 |
