Associated Spring Raymond - 12.2mm OD, 1.7mm Wire, 1/2" Free Length, Compression Spring - 150.5 Lb Spring Rating, 77 N Max Work Load, Stainless Steel
Item #: 69058485
Brand: Associated Spring Raymond
Model #: C04800670500X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 12.19 |
| Outside Diameter (Decimal Inch) | 0.4800 |
| Free Length (mm) | 12.70 |
| Free Length (Decimal Inch) | 1/2 |
| Spring Rate Pounds per Inch (Pounds) | 150.5000 |
| Maximum Work Load (N) | 77 |
| Solid Height (mm) | 8.53 |
| Solid Height (Decimal Inch) | 0.3360 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.70 |
| Wire Size (Decimal Inch) | 0.0670 |
