Associated Spring Raymond - 12.2mm OD, 1.6mm Wire, 76.2mm Free Length, Compression Spring - 15.16 Lb Spring Rating, 64.58 N Max Work Load, Stainless Steel
Item #: 69058469
Brand: Associated Spring Raymond
Model #: C04800633000S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 12.19 |
| Outside Diameter (Decimal Inch) | 0.4800 |
| Free Length (mm) | 76.20 |
| Free Length (Decimal Inch) | 3 |
| Spring Rate Pounds per Inch (Pounds) | 15.1600 |
| Maximum Work Load (N) | 64.58000183 |
| Solid Height (mm) | 32.28 |
| Solid Height (Decimal Inch) | 1.2710 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.60 |
| Wire Size (Decimal Inch) | 0.0630 |
