Associated Spring Raymond - 12.2mm OD, 1.6mm Wire, 35.05mm Free Length, Compression Spring - 35.6 Lb Spring Rating, 64.37 N Max Work Load, Stainless Steel
Item #: 69058345
Brand: Associated Spring Raymond
Model #: C04800631380X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 12.19 |
| Outside Diameter (Decimal Inch) | 0.4800 |
| Free Length (mm) | 35.05 |
| Free Length (Decimal Inch) | 1.3800 |
| Spring Rate Pounds per Inch (Pounds) | 35.6000 |
| Maximum Work Load (N) | 64.37000275 |
| Solid Height (mm) | 16.64 |
| Solid Height (Decimal Inch) | 0.6550 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.60 |
| Wire Size (Decimal Inch) | 0.0630 |
