Associated Spring Raymond - 12.2mm OD, 1.5mm Wire, 15.75mm Free Length, Compression Spring - 68 Lb Spring Rating, 54.38 N Max Work Load, Stainless Steel
Item #: 69058006
Brand: Associated Spring Raymond
Model #: C04800590620X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 12.19 |
| Outside Diameter (Decimal Inch) | 0.4800 |
| Free Length (mm) | 15-3/4 |
| Free Length (Decimal Inch) | 0.6200 |
| Spring Rate Pounds per Inch (Pounds) | 68.0000 |
| Maximum Work Load (N) | 54.38000107 |
| Solid Height (mm) | 8.79 |
| Solid Height (Decimal Inch) | 0.3460 |
| Material | Stainless Steel |
| Wire Size (mm) | 1-1/2 |
| Wire Size (Decimal Inch) | 0.0590 |
