Associated Spring Raymond - 12.2mm OD, 1.3mm Wire, 76.2mm Free Length, Compression Spring - 7 Lb Spring Rating, 36.28 N Max Work Load, Stainless Steel
Item #: 69057636
Brand: Associated Spring Raymond
Model #: C04800513000X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 12.19 |
| Outside Diameter (Decimal Inch) | 0.4800 |
| Free Length (mm) | 76.20 |
| Free Length (Decimal Inch) | 3 |
| Spring Rate Pounds per Inch (Pounds) | 7.0000 |
| Maximum Work Load (N) | 36.27999878 |
| Solid Height (mm) | 22.83 |
| Solid Height (Decimal Inch) | 0.8990 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.30 |
| Wire Size (Decimal Inch) | 0.0510 |
