Associated Spring Raymond - 12.2mm OD, 1.3mm Wire, 22.35mm Free Length, Compression Spring - 26.16 Lb Spring Rating, 36.56 N Max Work Load, Stainless Steel
Item #: 69057396
Brand: Associated Spring Raymond
Model #: C04800510880S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 12.19 |
| Outside Diameter (Decimal Inch) | 0.4800 |
| Free Length (mm) | 22.35 |
| Free Length (Decimal Inch) | 0.8800 |
| Spring Rate Pounds per Inch (Pounds) | 26.1600 |
| Maximum Work Load (N) | 36.56000137 |
| Solid Height (mm) | 8.97 |
| Solid Height (Decimal Inch) | 0.3530 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.30 |
| Wire Size (Decimal Inch) | 0.0510 |
