Associated Spring Raymond - 12.2mm OD, 1.14mm Wire, 1-1/4" Free Length, Compression Spring - 13 Lb Spring Rating, 40.92 N Max Work Load, Music Wire
Item #: 69057123
Brand: Associated Spring Raymond
Model #: C04800451250M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 12.19 |
| Outside Diameter (Decimal Inch) | 0.4800 |
| Free Length (mm) | 31-3/4 |
| Free Length (Decimal Inch) | 1-1/4 |
| Spring Rate Pounds per Inch (Pounds) | 13.0000 |
| Maximum Work Load (N) | 40.91999817 |
| Solid Height (mm) | 8.84 |
| Solid Height (Decimal Inch) | 0.3480 |
| Material | Music Wire |
| Wire Size (mm) | 1.14 |
| Wire Size (Decimal Inch) | 0.0450 |
