Associated Spring Raymond - 12.2mm OD, 1.14mm Wire, 1/2" Free Length, Compression Spring - 35 Lb Spring Rating, 40.92 N Max Work Load, Music Wire
Item #: 69057008
Brand: Associated Spring Raymond
Model #: C04800450500M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 12.19 |
| Outside Diameter (Decimal Inch) | 0.4800 |
| Free Length (mm) | 12.70 |
| Free Length (Decimal Inch) | 1/2 |
| Spring Rate Pounds per Inch (Pounds) | 35.0000 |
| Maximum Work Load (N) | 40.91999817 |
| Solid Height (mm) | 4.70 |
| Solid Height (Decimal Inch) | 0.1850 |
| Material | Music Wire |
| Wire Size (mm) | 1.14 |
| Wire Size (Decimal Inch) | 0.0450 |
