Associated Spring Raymond - 12.2mm OD, 1.07mm Wire, 1-1/2" Free Length, Compression Spring - 8.5 Lb Spring Rating, 34.7 N Max Work Load, Music Wire
Item #: 69056810
Brand: Associated Spring Raymond
Model #: C04800421500M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 12.19 |
| Outside Diameter (Decimal Inch) | 0.4800 |
| Free Length (mm) | 38.10 |
| Free Length (Decimal Inch) | 1-1/2 |
| Spring Rate Pounds per Inch (Pounds) | 8.5000 |
| Maximum Work Load (N) | 34.70000076 |
| Solid Height (mm) | 9.09 |
| Solid Height (Decimal Inch) | 0.3580 |
| Material | Music Wire |
| Wire Size (mm) | 1.07 |
| Wire Size (Decimal Inch) | 0.0420 |
