Associated Spring Raymond - 12.2mm OD, 0.97mm Wire, 50.8mm Free Length, Compression Spring - 4 Lb Spring Rating, 15.9 N Max Work Load, Stainless Steel
Item #: 69056539
Brand: Associated Spring Raymond
Model #: C04800382000X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 12.19 |
| Outside Diameter (Decimal Inch) | 0.4800 |
| Free Length (mm) | 50.80 |
| Free Length (Decimal Inch) | 2 |
| Spring Rate Pounds per Inch (Pounds) | 4.0000 |
| Maximum Work Load (N) | 15.89999962 |
| Solid Height (mm) | 9.86 |
| Solid Height (Decimal Inch) | 0.3880 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.97 |
| Wire Size (Decimal Inch) | 0.0380 |
