Associated Spring Raymond - 9.9mm OD, 1.2mm Wire, 14.22mm Free Length, Compression Spring - 46 Lb Spring Rating, 35.41 N Max Work Load, Stainless Steel
Item #: 69052710
Brand: Associated Spring Raymond
Model #: C03900470560X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.91 |
| Outside Diameter (Decimal Inch) | 0.3900 |
| Free Length (mm) | 14.22 |
| Free Length (Decimal Inch) | 0.5600 |
| Spring Rate Pounds per Inch (Pounds) | 46.0000 |
| Maximum Work Load (N) | 35.40999985 |
| Solid Height (mm) | 7.34 |
| Solid Height (Decimal Inch) | 0.2890 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.19 |
| Wire Size (Decimal Inch) | 0.0470 |
