Associated Spring Raymond - 9.9mm OD, 1.1mm Wire, 23.88mm Free Length, Compression Spring - 18.4 Lb Spring Rating, 27.31 N Max Work Load, Stainless Steel
Item #: 69052504
Brand: Associated Spring Raymond
Model #: C03900430940X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.91 |
| Outside Diameter (Decimal Inch) | 0.3900 |
| Free Length (mm) | 23.88 |
| Free Length (Decimal Inch) | 0.9400 |
| Spring Rate Pounds per Inch (Pounds) | 18.4000 |
| Maximum Work Load (N) | 27.30999947 |
| Solid Height (mm) | 9.12 |
| Solid Height (Decimal Inch) | 0.3590 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.09 |
| Wire Size (Decimal Inch) | 0.0430 |
