Associated Spring Raymond - 9.14mm OD, 1.5mm Wire, 3/4" Free Length, Compression Spring - 101 Lb Spring Rating, 70.5 N Max Work Load, Stainless Steel
Item #: 69051886
Brand: Associated Spring Raymond
Model #: C03600590750X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 9.14 |
| Outside Diameter (Decimal Inch) | 0.3600 |
| Free Length (mm) | 19.05 |
| Free Length (Decimal Inch) | 3/4 |
| Spring Rate Pounds per Inch (Pounds) | 101.0000 |
| Maximum Work Load (N) | 70-1/2 |
| Solid Height (mm) | 12.40 |
| Solid Height (Decimal Inch) | 0.4880 |
| Material | Stainless Steel |
| Wire Size (mm) | 1-1/2 |
| Wire Size (Decimal Inch) | 0.0590 |
